S6280 Standard Digital HV Ultra Torque High Speed Waterproof Metal Gear Surface Servo

S6285 1/8 High Voltage High Torque Metal Gear Race Servo
Spektrum - SPMSS6285
S6285 1/8 High Voltage High Torque Metal Gear Race Servo
View Alternate Product Details

Key Features

  • Removable wire harness with different lengths available
  • 7075 Aluminum hard anodized output shaft/main gear with steel internal gears
  • Aluminum case for good heat dissipation
  • Aluminum mounting tabs
  • NMB dual main bearings
  • 23T output shaft
  • Waterproof
  • 1-Year Limited Warranty

Overview

The latest generation of Spektrum surface servos provides you with the performance you need for any 1/10th to 1/8th scale vehicle application. The S6230 and S6240 offer high-torque or high-speed performance in a more compact size for 1/10th scale crawlers or monster trucks where space is limited. The S6250 HV and S6260 HV are standard size servos for High-Voltage applications up to 8.4V, And the S6280 HV and S6290 HV feature all metal case construction for the ultimate 1/8th scale performance. All these servos feature Spektrum innovations like the removable wire leads that allow for custom lead length and ease of maintenance and all metal servo mounting tabs to keep them in place through the most extreme conditions.

Product Specs

Application
Surface
Bearing
Dual
Bushing Or Bearing
Bearing
Current Draw Idle
10.2mA @ 6.0V
Current Draw Stall
4900mA @ 6.0V
Gear Type
Metal
Material
Metal
Maximum Servo Torque
364 oz-in (26.2kg-cm) @ 6V; 440 oz-in (31.7kg-cm) @ 7.4V; 496 oz-in (35.7kg-cm) @ 8.4V
Motor Type
Brushed
Part Type
Electronics
Product Application
Surface
Product Height
1.38 in (35.1mm)
Product Length
1.61 in (41mm)
Product Weight
2.8 oz (79.4g)
Product Width
0.82 in (20.8mm)
Programmable
No
Servo Operating Voltage
6.0 - 8.4V (HV)
Servo Size Category
Standard
Servo Type
Digital
Spline Count
23 Teeth
